PDM workflow explained: revision control, approvals & release
How a PDM workflow really works — from CAD file creation and revision control to approvals, release, supplier collaboration, and change management for SMEs.
TABLE OF CONTENTS
Direct answer: A PDM workflow is the process engineering teams use to manage CAD files from creation to revision, review, approval, release, and change. It controls who can edit files, which version is current, who needs to approve changes, and when a design is ready for manufacturing, suppliers, or customers — something shared drives, email, and manual file naming cannot reliably do.
Without a clear PDM workflow, engineering teams usually end up relying on shared drives, email attachments, manual file naming, and informal approvals. That works at first, but it quickly leads to duplicate files, overwritten work, wrong revisions reaching suppliers, and confusion between designers, managers, and manufacturing partners.
One university engineering team described the pain simply: they were "very excited to get away from the Google Drive CAD PDM" because it was "not the greatest."
A PDM (Product Data Management) workflow gives that process structure. It defines how CAD files, drawings, documents, revisions, and approvals move through the engineering process, and makes that movement visible to everyone involved — from the engineer drafting a part to the supplier producing it.
This article explains how a typical PDM workflow works, what each stage does, where shared drives break down, and what a good cloud PDM workflow should include for small and mid-sized engineering teams.
What is a PDM workflow?
A PDM workflow is a structured way to manage product design data. In a typical engineering team, a part or assembly may go through several stages:
- Work in progress
- Internal review
- Approval
- Released for manufacture
- Revised or changed later
PDM software makes these stages visible and controlled. Instead of relying on file names like
final_v3_APPROVED_revised.step, the system tracks status, ownership, revision history, and permissions — so the team always knows which version is current and who is responsible for it.The stages of a typical PDM workflow
Stage | What happens | Typical roles involved |
Work in progress | Engineer creates or edits CAD files and supporting documents | Design engineer |
Check-in / check-out | Files are locked while edited and unlocked when changes are saved | Design engineer |
Revision | A new version is recorded; previous revisions are preserved | Design engineer |
Review | Reviewers comment, request changes, or approve | Lead engineer, project manager, quality, manufacturing |
Approval | Files are accepted or rejected based on review feedback | Manager / approver |
Release | The design becomes the official version for use | Engineering, manufacturing, suppliers |
Change management (ECO) | An Engineering Change Order documents the reason, approves a new revision, and notifies affected teams | Engineer, QA, manufacturing, supplier, customer, manager |
A typical PDM workflow, step by step
1. Create or upload the CAD file
The workflow starts when an engineer creates or uploads a CAD file. This may be a part, assembly, drawing, STEP file, PDF, or supporting document.
At this stage, the file is usually marked as work in progress. The engineer can keep editing it, but other users should be able to see clearly that it is not yet released or approved.
2. Add metadata and structure
Good PDM workflows do not only store files. They also store information about those files, such as:
- Part number
- Project
- Customer
- Material
- Revision
- Owner
- Status
- Related drawings or assemblies
This metadata makes it easier to search, filter, reuse, and understand design data later. It also reduces the need to rely on folder structures or long file names to keep track of context.
3. Control edits with check-in and check-out
In many PDM workflows, engineers use check-in and check-out to avoid overwriting each other's work. If one person is editing a file, others can see that the file is locked or in progress.
This prevents common shared-drive problems, such as two people editing different copies of the same file, or accidentally replacing the latest version with an older one.
4. Manage revisions
Revision control is one of the core functions of PDM. When a design changes, the system records a new revision rather than losing the old version.
A basic revision process may look like this:
- Revision A: first approved version
- Revision B: updated after design change
- Revision C: released after manufacturing feedback
The goal is to make it clear which version is current, which versions are historical, and why a change was made.
Cloud PDM platforms such as CAD ROOMS keep that record in version history automatically — every check-in becomes a new revision, with the previous versions, owners, and timestamps preserved alongside it.
For growing engineering teams, the shift from informal file storage to formal revision control can become a major turning point. One biotech engineering lead described a formal revision control system as a "major improvement" as their team prepared to scale.
5. Send files for review
Once the engineer is ready, the file moves into review. Reviewers may include senior engineers, project managers, quality teams, manufacturing teams, or external suppliers.
During review, people may:
- Add comments
- Request changes
- Compare versions
- Check drawings
- Confirm manufacturability
- Approve or reject the file
Review is important because it creates a record of the decision-making process. Instead of approvals being hidden in email threads or chat messages, they are connected directly to the design file and its revision.
Cloud-native platforms such as CAD ROOMS handle this step directly in the browser — reviewers can open the model in the 3D Viewer, measure parts, view section or exploded views, and add comments or annotations without exporting files or installing CAD plugins.
6. Approve and release
After review, the file can be approved and released. A released file is the version the business considers ready for use.
Depending on the company, release may mean:
- Ready for manufacturing
- Ready to send to a supplier
- Ready for customer approval
- Ready for purchasing or quoting
- Ready to archive as the official design record
Once released, permissions often become stricter. Only authorized users may be able to revise the file, and changes may require a formal change request.
Release is also where the design becomes a product record, not just a file. A properly released revision is tied to its bill of materials (BOM), the drawings and derived files (PDF, STEP, DXF) that go with it, and an effectivity marker — typically a date, serial number, or lot — so manufacturing and suppliers know exactly which builds the new revision applies to.
7. Manage changes after release
Designs often change after release. A good PDM workflow makes that change controlled rather than chaotic.
When a released file needs to change, the team should be able to see:
- What changed
- Who requested the change
- Why the change was needed
- Which revision is affected
- Who approved the new version
- Whether suppliers or manufacturers need to be notified
This is especially important for teams working with external partners, because using the wrong revision can cause delays, rework, and costly manufacturing errors.
ECR, ECO, ECN: the change-control vocabulary
Most engineering teams — and almost all teams working to ISO 9001, AS9100, or similar quality standards — break post-release change into three artifacts:
- ECR (Engineering Change Request): the proposal. Someone (engineer, supplier, customer, QA) describes a problem or improvement and the parts or assemblies it affects.
- ECO (Engineering Change Order): the approved change. The ECO links the old revision to the new revision, records the reason, the affected BOM items, the approvers, and the effectivity.
- ECN (Engineering Change Notice): the communication. The ECN tells manufacturing, suppliers, and other stakeholders that a new revision is now effective and the previous one is superseded.
For regulated industries (aerospace, medtech, defence), the ECO itself is the audit artifact — it is what an auditor will ask to see when checking that a change was properly reviewed, approved, and communicated.
In CAD ROOMS, post-release changes are structured as an Engineering Change Order (ECO) — the change request, affected revisions, approver, and final released version are tracked on the same record, so suppliers and manufacturers know exactly which version supersedes the previous one.
Where suppliers and manufacturers fit in
For most engineering businesses, the PDM workflow does not stop at the company's own engineers. Suppliers, manufacturers, and sometimes customers also rely on the right version of the design.
A controlled PDM workflow should make sure:
- Suppliers receive only released, approved files — not work-in-progress versions
- External access is limited to specific projects, folders, or files
- Supplier feedback can flow back into the system as comments or change requests
- Released revisions are easy to identify, even months later
- Manufacturing files are not shared via uncontrolled email attachments or personal links
When suppliers cannot easily access the PDM system, teams often fall back to email or shared links to send STEP files, drawings, and instructions. That undoes most of the value of the workflow, because the supplier ends up working from a copy that the PDM system no longer tracks. For distributed teams, secure supplier collaboration needs to be part of the workflow itself.
This is one of the strongest reasons SMEs adopt cloud PDM specifically: supplier collaboration should not require VPNs, exported ZIP files, uncontrolled email attachments, or full paid seats for every external partner. A cloud-native PDM workflow should let teams share the right released files with the right people, without exposing work-in-progress designs or creating disconnected copies.
One aerospace startup described the value of controlled sharing clearly: being able to share a live view of how CAD data is managed was "incredibly useful" because it was something their team lacked.
Why shared drives struggle with PDM workflows
Shared drives such as Dropbox, Google Drive, OneDrive, or generic file servers are useful for basic storage. They are not designed for engineering workflows, and the gap becomes obvious as soon as a team starts working with revisions, approvals, and external partners. This is why many teams eventually look for a Google Drive alternative for CAD data management or a OneDrive alternative for CAD files.
Workflow need | With shared drives | With PDM |
Revision control | Manual file names like final_v3_APPROVED | Automatic, structured revisions |
Approval status | Hidden in emails or chat | Linked to the file and its revision |
Edits | Risk of overwrites and duplicate files | Check-in / check-out and version history |
Audit trail | Limited or none | Full history of changes and approvals |
Supplier access | Email, shared links, ad-hoc folders | Controlled, permission-based access to released files |
Searchability | Folder names and file names | Metadata, status, project, and revision filters |
Risk of using wrong file | High | Low — latest released version is clearly identified |
The issue is not only storage. It is the absence of a controlled workflow around design data — which is exactly what PDM is built to provide.
What a good cloud PDM workflow should include
A strong cloud PDM workflow should include:
- Clear file status: work in progress, review, approved, released
- Revision history
- Role-based permissions
- Review and approval steps
- Change control (ECRs, ECOs, ECNs) tied to revisions and BOMs
- Secure supplier and manufacturer access
- Searchable metadata
- Audit trails
- Easy access from anywhere
- Minimal IT maintenance
For small and mid-sized engineering businesses, cloud PDM is especially helpful because it offers this level of workflow control without the heavy infrastructure and administration usually associated with traditional PDM systems. Teams comparing options can also review the best cloud PDM solutions for SMEs. The goal is not to add more process; it is to remove the informal workarounds that create the most risk — manual naming, email approvals, uncontrolled supplier sharing, and uncertainty about which revision is current. Teams that need more formal release and ECO processes can also evaluate cloud PDM platforms with customizable workflows.
How CAD ROOMS supports a cloud PDM workflow
CAD ROOMS is built for SMEs and hardware teams that want a structured PDM workflow without the cost and complexity of traditional on-premise PDM. The platform handles version control, check-in / check-out, revision history, Engineering Change Orders (ECOs), release, and audit logs as part of the standard product — not as paid add-ons or plugins.
Review and approval happen inside CAD ROOMS' built-in 3D Viewer, so engineers, managers, and reviewers can inspect models, run measurements, and add annotations directly on the file. Because every comment is tied to a specific revision, the approval trail stays connected to the design instead of being scattered across email or chat.
For teams evaluating file-based PDM for multi-CAD teams, CAD ROOMS natively supports 30+ CAD and 3D file formats, including SOLIDWORKS, CATIA, Creo, NX, Inventor, Fusion 360, STEP, and IGES. A single workflow can therefore cover designs from different CAD vendors without forced conversions or separate PDM stacks per CAD tool.
External collaboration is handled through file-based Guest Sharing: suppliers, manufacturers, and clients get read-only access only to the released files explicitly shared with them, without becoming workspace members or consuming seats. The result is a workflow where internal engineers, external partners, and historical revisions all sit under one controlled record — without VPNs, plugins, or manual file transfers.
Example: a real-world PDM workflow for an SME
To make this concrete, imagine a 10-person engineering team that designs custom mechanical assemblies for industrial customers. They work with 5 suppliers and 2 contract manufacturers.
A typical workflow for one component might look like this:
- A design engineer creates a new bracket assembly in their CAD tool and uploads it to the PDM system.
- The file is automatically tagged with the project, customer, and part number, and marked as Work in progress.
- The engineer checks the file out, refines the geometry, and checks it back in as Revision A.
- The engineer sends Revision A for review.
- The lead engineer requests a small change to a mounting hole. The reviewer's comment is attached to the revision.
- The engineer updates the file and submits Revision B.
- The lead engineer approves Revision B.
- The project manager triggers a release, which makes Revision B the official version.
- The supplier is given access to the released STEP and drawing files only.
- Two months later, the manufacturer reports a tolerance issue. An ECR is raised describing the problem and the affected parts. After review it is approved as an ECO linking Revision B → Revision C, with the reason, affected assemblies, approvers, and effectivity date recorded on the ECO. Once Revision C is released, an ECN notifies the supplier and internal manufacturing that Revision C is now effective and supersedes Revision B.
At every stage, the team can see:
- Which revision is current
- Who approved it
- Why it changed
- Who has access
- What the supplier received
That visibility is the difference between a controlled engineering workflow and one that depends on memory, file names, and email.
Common signs your team needs a PDM workflow
Many SMEs do not adopt PDM until shared drives stop working for them. Common signals include:
- Engineers regularly ask "which version is the latest?"
- Suppliers receive the wrong revision
- Approvals live in email threads or chat
- File names try to encode revision and status (
final_v3_APPROVED.step)
- Multiple people edit different copies of the same file
- It is difficult to find historical revisions or past approvals
- New team members struggle to navigate folder structures
- Manufacturing rework is caused by outdated CAD files
If several of these signs are present, the team has likely outgrown shared drives and needs a structured PDM workflow.
FAQ
Q: What is a PDM workflow?
A: A PDM workflow is the process used to manage CAD files and product data through creation, revision, review, approval, release, and change management.
Q: How does PDM revision control work?
A: PDM revision control keeps a record of design changes over time. Instead of replacing old files, the system preserves previous versions and clearly identifies the latest approved revision.
Q: How does PDM approval work?
A: In a PDM approval workflow, files move from work in progress into review, where designated approvers can comment, request changes, or approve the design. Approved files can then be released as the official version.
Q: Why is PDM better than a shared drive for engineering workflows?
A: PDM provides structured revision control, permissions, approval status, audit trails, metadata, and controlled supplier access. Shared drives mainly provide storage and rely on manual file naming and informal processes.
Q: How does CAD ROOMS handle revisions, approvals, and ECOs?
A: CAD ROOMS treats revision control, approvals, and Engineering Change Orders as part of the standard workflow — not paid add-ons. Engineers check files in and out, every change creates a new entry in version history, and post-release changes flow through a structured ECO process with clear ownership and audit logs.
Q: How does CAD ROOMS support supplier collaboration in a PDM workflow?
A: External suppliers, manufacturers, and clients access files through file-based Guest Sharing. Guests view files in the 3D Viewer with read-only permission, can add comments and annotations, do not consume seats, and never see other projects or work-in-progress files. Access can be revoked at any time.
Q: Does CAD ROOMS support multi-CAD or mixed-format engineering teams?
A: Yes. CAD ROOMS natively supports 30+ CAD and 3D file formats, including SOLIDWORKS, CATIA, Creo, NX, Inventor, Fusion 360, STEP, and IGES. Mixed-CAD teams can run revision control, review, approval, and supplier sharing across all formats inside one workflow without converting files or running multiple PDM stacks.
Conclusion
A PDM workflow is not about adding process for its own sake. It is about giving the engineering team a clear, shared answer to questions like:
- Which revision is current?
- Who approved it?
- What changed?
- What did the supplier receive?
For small and mid-sized engineering businesses, the right PDM workflow turns CAD data from a folder full of files into a controlled engineering record — without requiring heavy IT, consultants, or complex on-premise infrastructure. Teams comparing the economics can also review cloud PDM vs on-premise PDM costs.
If your team is still relying on shared drives, manual file names, or email approvals, the most useful starting point is to map your current workflow: where files are created, who reviews them, how they get approved, and how suppliers receive the final version.
Once that workflow is mapped, use a PDM deployment timeline to plan rollout, then look for the points where the process depends on memory, manual naming, exported files, email approval, or uncontrolled supplier sharing. Those are usually the areas where cloud PDM creates the fastest return — by reducing revision mistakes, approval delays, supplier confusion, and avoidable rework.
CAD ROOMS is built to help engineering teams run a structured PDM workflow — revision control, approvals, ECOs, controlled supplier sharing, and multi-CAD support — without the IT overhead of traditional PDM. To see how it fits your team, you can book a CAD ROOMS demo, explore the CAD ROOMS PDM platform, or learn more about cloud PDM workflows.
